Garage Door Weather Stripping: Seal Types and How to Replace

Garage door weather stripping is the set of rubber and vinyl seals that close the gaps around your garage door. When it works, it keeps out drafts, rain, leaves and insects. When it wears out, the garage turns colder in winter, damper after storms and more inviting to pests. Fortunately, most seals are inexpensive and easy to replace.

Last reviewed and updated: October 2, 2026. Written by Jeremy Jarvis.

This guide explains each type of garage door weather stripping, how to spot worn seals, and how to measure and replace them. It also covers threshold seals for uneven floors and the simple checks that keep new seals working for years.

Why garage door weather stripping matters

A garage door is a large opening with long edges. Even a small gap along the bottom adds up to a lot of open area across a full door. That gap lets in cold air, water and debris every day. In addition, it gives mice and insects an easy route into the garage and, from there, into the house.

ENERGY STAR lists installing weather stripping on doors among the simple fixes that improve home comfort and savings. A garage may not be heated, but it often shares a wall, a ceiling or a door with living space. Therefore, a drafty garage can make the rooms beside it feel colder too.

Seals also protect what you store. Water that blows under the door can rust tools, damage boxes and leave puddles that never fully dry. Over time, that dampness feeds mold and mildew.

Signs your garage door seals are worn

Seals wear out slowly, so the signs are easy to miss. The simplest test is to close the door on a bright day, turn off the garage lights and look along the edges. Any daylight you see is a gap that air and water can use.

Other signs are just as telling. For example, a puddle inside the door after rain points to the bottom seal or the floor slope. Leaves and dirt collecting inside the door line are another clue. You may also notice cracked, brittle or flattened rubber, or a seal that has pulled out of its channel at one end. Finally, insects or mouse droppings near the door often mean there is a gap low on one side.

Check the seals each season. Our Garage Safety and Maintenance Checklist includes a quick seal inspection with the other seasonal tasks.

Types of garage door weather stripping

A garage door has several separate seals, and each one closes a different gap. Knowing which is which helps you buy the right part.

Most problems start at the bottom, since that seal takes the most abuse. Still, a full inspection often finds worn side stops too.

Bottom seal profiles and retainers

The bottom seal is the most important piece of garage door weather stripping, and it is also the easiest to buy wrong. On most steel doors, the seal slides into an aluminum or vinyl retainer channel fastened to the bottom of the door. The edges of the seal must match the shape of that channel.

Common edge shapes include T-style ends, beaded ends and other profiles specific to a door brand. Meanwhile, the part that touches the floor comes in different shapes too. Bulb seals form a hollow tube that squashes against the floor. J-type and flat seals curl or fold against the floor instead. Many wood doors skip the retainer and use a seal nailed or screwed directly to the bottom edge.

To identify yours, open the door to about waist height and look at the bottom from the end. Note the retainer shape, then pull a short length of the old seal out of one end and take it with you, or photograph it beside a ruler.

How to measure for a new bottom seal

Measuring is simple but important. First, measure the full width of the door from edge to edge, then add a little extra for trimming. Next, measure the width of the seal itself and the size of the channel slots it slides into. Finally, check the gap between the floor and the bottom of the door at its worst point.

That last measurement guides the seal height. A bulb seal can close a modest gap, while a larger gap on an uneven floor may need a taller seal or a threshold. If the gap is much larger at one end, the floor may have settled or the door may be out of level. In that case, a seal alone may not solve the problem.

How to replace a garage door bottom seal

Replacing a bottom seal on a steel door with a retainer usually takes an hour or two. You need a helper, a flat screwdriver, a utility knife, a little dish soap and a pair of locking pliers or clamps.

1. Open the door to about waist height and unplug the opener or disconnect it so the door cannot move.
2. Clamp the track just below a roller on each side as a safety stop.
3. Pull the old seal out of the retainer, working from one end.
4. Clean the channels and check the retainer for bent or corroded sections.
5. Spray the channels with soapy water to help the new seal slide.
6. Feed both edges of the new seal into the channels while a helper pulls it through.
7. Center the seal, trim the ends with a little overhang and crimp the retainer ends lightly.
8. Remove the clamps, reconnect the opener and test the door.

After installation, close the door and check for light again. Then run the opener’s safety reversal test, since a thicker seal changes where the door meets the floor. If the door reverses on its own when closing, adjust the opener’s close limit according to its manual.

Replacing perimeter stop molding

The perimeter seal, often called stop molding, runs along the two side jambs and the header. It usually has a rigid backing with a flexible flap that presses lightly against the door when it is closed. Over time, sun and weather make the flap brittle, and gaps appear along the sides.

To replace it, pry off the old molding and remove the nails or screws. Then cut the new molding to length, starting with the header piece. Hold each piece so the flap just touches the closed door, without pushing hard against it. If it presses too tightly, the door will drag and the opener may sense resistance. Fasten the pieces with galvanized nails or screws, and seal the outside edge with exterior caulk if needed.

Vinyl stop molding resists rot better than wood-backed versions. However, pick a color and finish that suits the trim, since this piece is visible from the street.

When a threshold seal helps

A threshold seal is a raised rubber strip glued to the garage floor where the door closes. The bottom seal presses down onto it, creating a better seal. It is especially useful on uneven floors and on floors that slope toward the garage, where rain runs inside.

Before installing one, clean the floor well and let it dry. Then dry-fit the strip, mark its position with the door closed, and glue it with the adhesive the maker recommends. Keep in mind that a threshold creates a small bump to drive over. As a result, it may not suit a garage used as a gym or workshop where carts roll in and out.

Sealing the joints between sections

Sectional doors have joints where the panels meet. Many insulated doors use tongue-and-groove or shiplap joints with built-in seals that close tightly when the door shuts. Older single-skin doors may have plain joints that leak air and light.

If you see light between sections on a closed door, first check that the door is aligned and the hinges are tight. A loose hinge can let one section sag. If the joints themselves leak, joint seal kits or a new insulated door are the main options. For more on that upgrade, see our insulated garage door guide.

Weather stripping and insulation together

Seals and insulation work as a team. Insulation slows heat moving through the door panels, while weather stripping stops air moving around them. Even a well-insulated door loses much of its benefit if air pours under the bottom edge.

For that reason, replace worn seals before or alongside any insulation project. Likewise, if you add an insulation kit to an existing door, check that the perimeter stops still close lightly against the thicker panels. Our guide to insulating a garage door covers that project step by step.

Seals, moisture and mold

Water blowing under the door is one of the main sources of garage dampness. EPA notes that the key to mold control is moisture control, and it advises acting quickly when water leaks occur indoors. It also suggests keeping indoor humidity below 60 percent, ideally between 30 and 50 percent.

Good garage door weather stripping is the first defense, but it is not the only one. Also check that the driveway and floor slope away from the door, that gutters drain away from the garage, and that wet cars have room to drip dry. If the garage still feels damp, our garage dehumidifier guide explains how to size one.

Caring for garage door seals

New seals last longer with a little care. Wipe the bottom seal and threshold clean a few times a year, since grit wears rubber quickly. Keep the area under the door clear of ice in winter so the seal does not freeze to the floor and tear when the door opens.

In addition, avoid petroleum-based products on rubber seals, as some can soften or swell them. If you lubricate the door’s rollers and hinges, keep the spray off the seals. Lastly, recheck the seals each season and after any repair that changes how the door sits in the opening.

DIY or professional seal replacement

Most seal jobs are well within DIY reach. A bottom seal in good retainers and new perimeter stops need only basic tools and an afternoon. HomeGuide notes that simple garage door repairs may start under $100, but minimum service fees can apply when you call a pro.

However, call a technician if the retainer is badly damaged, the door is out of level, or the gap is caused by a spring or cable problem. Springs and cables are under high tension and should never be adjusted by a homeowner.

Garage door weather stripping checklist

• Look for light, water, leaves and insects along the door edges.
• Identify the bottom retainer type and seal profile.
• Measure door width, seal width and the floor gap.
• Replace the bottom seal with a helper and the door secured.
• Replace brittle side and header stop molding.
• Add a threshold seal on sloped or uneven floors.
• Test the opener’s safety reversal after any seal change.

Where to compare garage door seals

Once you know your retainer profile and door width, compare current garage door bottom seals, threshold seals and perimeter weather stripping. Check the profile and width on each listing before you order. For more door care guides, visit the Garage Doors and Openers hub.

Frequently asked questions about garage door weather stripping

How do I know if my garage door weather stripping needs replacing?

Close the door on a bright day and look for light along the bottom and sides. Daylight, drafts, water on the floor after rain, leaves or insects inside, and cracked or flattened rubber all mean the seal is worn or no longer fits.

What type of bottom seal does my garage door need?

The bottom seal must match the retainer channel on the bottom of the door. Steel doors often use a slide-in seal with T-shaped or beaded edges, while many wood doors use a seal nailed directly to the bottom edge. Check the profile before you buy.

Do garage door threshold seals work?

A threshold seal is a raised rubber strip glued to the floor under the door. It works well where the floor is uneven or slopes toward the garage, because it gives the bottom seal a level surface and helps keep out water and debris.

Can garage door weather stripping help with moisture and mold?

It helps by keeping rain and snowmelt out. EPA notes that the key to mold control is moisture control and suggests keeping indoor humidity below 60 percent, ideally between 30 and 50 percent. Good seals are one part of that plan.

Should I hire a pro to replace garage door seals?

Most homeowners can replace a bottom seal and perimeter stops with basic tools. HomeGuide notes that simple garage door repairs may start under $100, though minimum service fees can apply. Leave springs and cables to a trained technician.

Sources and how we researched this guide

This guide is research-based. We did not install seals for this article; we compared common seal designs and used ENERGY STAR’s sealing guidance, EPA’s moisture and mold guidance and HomeGuide’s garage door repair cost data. Always match a replacement seal to your door’s retainer and follow the maker’s instructions. Found something out of date? Tell us and we will check it against the source.

• ENERGY STAR: Seal and insulate
• HomeGuide: Garage door repair cost
• EPA: A brief guide to mold, moisture and your home
